KPG-49D software is a tool for programming the TK-780/880/280/380/980/981/480/481 transceiver. (TK-980/981/480/481 does not have Conventional Format) Using this software, first enter programming data into the computer, and then transfer the data to a transceiver. You can print out the data on a printer. You can also retrieve data from a transceiver to edit on the computer. APPLICABLE TRANSCEIVERS This programming software supports the following transceivers: Conventional Format TK-780 (Mobile;VHF) TK-880 (Mobile;UHF) TK-280 (Portable;VHF) TK-380 (Portable;UHF) Trunking Format TK-780 (Mobile;VHF) TK-880 (Mobile;UHF) TK-280 (Portable;VHF) TK-380 (Portable;UHF) TK-980 (Mobile;800MHz) TK-981 (Mobile;900MHz) TK-480 (Portable;800MHz) TK-481 (Portable;900MHz) HARDWARE/ SOFTWARE REQUIREMENTS: This software is designed for use on an IBM PC, PS/2 and compatible computers with 10 Mbytes hard disk space, 32 Mbytes RAM.
Super VGA monitor or better. 800X600 or higher resolution recommended. The operating system must be Microsoft Windows 98/2000/Me/XP. Biomecanica Deportiva Libro Pdf. The computer must have a serial communication port to connect to a transceiver and be compatible with an IBM asynchronous communications adapter. You may select from the COM1-COM20 port on the computer.
Kenwood KPG-49D RSS Programming Software Please log in to download this item. Version 4.20 for Windows. Additional information Programming Software for: TK-280. Find best value and selection for your KENWOOD KPG 49D RADIO SOFTWARE search on eBay. World's leading marketplace. Kenwood KPG-49D v4.02 Programming Software KENWOOD OEM KENWOOD KPG-49D v4.02 PROGRAMMING SOFTWARE CD Works with the following radios TK-280, TK-380, TK-780, TK-880.
Use a Kenwood KPG-36(for portable) or a KPG-46(for mobile) programming cable to connect the computer to the transceiver. A commercially available DB-25 male to DB-9 female adapter may be needed depending on the port configuration of your computer. Download Harris Farinon Starlink Program on this page. Caution: The computer resources may run short if you run the KPG-49D and other software simultaneously.
CONNECTING THE EQUIPMENT PROCEDURE: 1. Switch OFF the power to the computer. Connect the 25-pin connector on the KPG-36/46 cable to the COM1 - COM20 port on the computer. If the computer's COM port has 9 pins, use the DB-25M to DB-9F adapter. Switch ON the power to the computer. Power OFF the transceiver. Connect the other end of the KPG-36/46 cable to the universal connector on the transceiver.
Kpg 49D 4 20 Download Free. KPG-29D v.4.00 - The programming cable is intended to be used with a computer RS-232 port for programming radios and other devices.
Power ON the transceiver. PROGRAMMING OVERVIEW PROGRAMMING METHODOLOGY: This section explains three typical programming operations. Note: When the programming data is transferred from the PC to the transceiver (writing the programming data) or vice versa (reading the programming data), the transceiver will automatically enter PC mode. 'PROGRAM' appears on the display. CREATING AND WRITING NEW DATA TO TRANSCEIVER 1. Specify the transceiver model you want to program. Input all necessary data.
(Channel Information, Edit/Optional Features, etc.) 3. Write the data to the transceiver. (Program/Write Data to Radio) 4. Save the data to a disk if desired. (File/Save As) MODIFYING DATA PREVIOUSLY WRITTEN TO A TRANSCEIVER 1. Read the transceiver data.
(Program/Read Data from Radio) 2. Modify the data. (Channel Information, Edit/Optional Features, etc.) 3.
Write the modified data to the transceiver. (Program/Write Data to Radio) 4. Save the data to a disk if desired. (File/Save As) MODIFYING DISK DATA, THEN WRITING TO A TRANSCEIVER 1. Read the disk data. (File/Open) 2.
Modify the data. (Channel Information, Edit/Optional Features and so on) 3.
Write the data to the transceiver. (Program/Write Data to Radio) 4. Save the data to a disk if desired. (File/Save As) Data File name Size 3.49 MB Downloads 606 Language English License Author Website File name: Size: 3.49 MB Please register or login to download files from this category.
